Truck Mounts
Challenger TA1204
Truck Mount
 |
|---|
Technical Specifications
-
Working Height: 12m
-
Max horizontal reach: 4m
-
Platform capacity: 1 man
-
Platform Capacity: 200kg
-
Platform size: 750mm x 1200mm
-
2 x Flapdown Outriggers
-
360 degree non-continuous rotation
-
Power source: PTO
-
Hydraulic operated control valve on the ground and electric operated from cage
-
Manual override in the event of system failure
-
Emergency Handpump
Challenger TA1206
Truck Mount
 |
|---|
Technical Specifications
-
Working Height: 12m
-
Max horizontal reach: 6m
-
Platform Capacity: 2 man ,250kg
-
Platform size: 750mm x 1200mm
-
4 x hydraulic stabilizers with leg lock valve
-
360 degree non-continuous rotation
-
Power source: PTO
-
Hydraulic operated control valve on the ground and electric operated from cage
-
Manual override in the event of system failure
-
Polyethylene 2 man work basket 1000kv
-
Emergency Handpump
Challenger CT12
Truck Mount
 |
|---|
Technical Specifications
-
Working Height: 12m
-
Max horizontal reach: 6m
-
Platform Capacity: 2 man ,250kg
-
Platform size: 750mm x 1200mm
-
4 x hydraulic stabilizers with leg lock valve
-
360 degree non-continuous rotation
-
Power source: PTO
-
Hydraulic operated control valve on the ground and electric operated from cage
-
Manual override in the event of system failure
-
Emergency Handpump
Challenger CT14
Truck Mount
 |
|---|
Technical Specifications
-
Working Height: 14m
-
Max horizontal reach: 6m
-
Platform Capacity: 2 man ,250kg
-
Platform size: 750mm x 1200mm
-
4 x hydraulic stabilizers with leg lock valve
-
360 degree non-continuous rotation
-
Power source: PTO
-
Hydraulic operated control valve on the ground and electric operated from cage
-
Manual override in the event of system failure
-
Emergency Handpump
Challenger CT16
Truck Mount
 |
|---|
Technical Specifications
-
Working Height: 16m
-
Max horizontal reach: 9m
-
Platform Capacity: 2 man ,250kg
-
Platform size: 750mm x 1200mm
-
4 x hydraulic stabilizers with leg lock valve
-
360 degree non-continuous rotation
-
Power source: PTO
-
Hydraulic operated control valve on the ground and electric operated from cage
-
Manual override in the event of system failure
-
Emergency Handpump
Challenger CT18
Truck Mount
 |
|---|
Technical Specifications
-
Working Height: 18m
-
Max horizontal reach: 7m
-
Platform Capacity: 2 man ,250kg
-
Platform size: 750mm x 1200mm
-
4 x hydraulic stabilizers with leg lock valve
-
360 degree non-continuous rotation
-
Power source: PTO
-
Hydraulic operated control valve on the ground and electric operated from cage
-
Manual override in the event of system failure
-
Emergency Handpump
Challenger CT22
Truck Mount
 |
|---|
Technical Specifications
-
Working Height: 22m
-
Max horizontal reach: 8m
-
Platform Capacity: 2 man ,250kg
-
Platform size: 750mm x 1200mm
-
4 x Extendable H-Frames with hydraulic stabilizers and leg lock valves
-
360 degree non-continuous rotation
-
Power source: PTO
-
Hydraulic operated control valve on the ground and electric operated from cage
-
Manual override in the event of system failure
-
Emergency Handpump
